ASUS TUF GAMING Z790-PLUS WIFI LGA 1700 ATX Motherboard

ASUS Z790-PLUS WiFi Overview

Bring speed and connectivity to your build with the TUF GAMING Z-790 PLUS WIFI LGA 1700 ATX Motherboard from ASUS. Utilizing the Intel Z790 chipset and LGA 1700 socket, this motherboard is compatible with 13th Gen Intel processors. Install up to 192GB of DDR5 RAM across four memory slots. Four M.2 and four SATA III interfaces allow for ample storage, while PCIe 5.0 x16, 4.0 x16, 4.0 x4, and two 3.0 x1 slots accommodate adapter cards.

Connect to wired peripherals via USB-C 3.2 Gen 2x2 and 3.2 Gen 2 ports, or via two USB-A 3.2 Gen 2 and four 3.2 Gen 1 ports. Output video via DisplayPort 1.4 or HDMI 2.1 interfaces. An RJ45 port supports 2.5 Gigabit Ethernet, and the included antenna allows for Wi-Fi 6E connectivity. The rear I/O panel also sports five 1/8" audio jacks and a S/PDIF output for digital audio. Internal headers provide support for fans, Clear CMOS, Thunderbolt 4, RGB lighting, and front-panel USB-C 3.2 Gen 2 and USB-A 3.2 Gen 1 and 2.0 ports. The ASUS TUF GAMING Z-790 PLUS WIFI LGA 1700 ATX Motherboard is compatible with Windows 10 and 11 64-bit operating systems.

Intel LGA 1700 Socket

The Intel LGA 1700 socket is compatible with 13th Gen Intel Core processors.

Z790 Chipset

Compatible with 13th Gen or Raptor Lake CPUs, this chipset is optimized for overclocking support and fast performance.

Enhanced Power Solution

A 16+1 Phase Power DrMOS, six-layer PCB, ProCool sockets, alloy chokes, and durable capacitors allow for stable power delivery.

Connectivity to the Core

Connect to fast internals and accessories using PCIe 5.0 and Thunderbolt 4 headers, plus support for a front-panel USB-C 3.2 Gen 2x2 port.

Made for Online Gaming

Hop online and keep abreast of the action with Wi-Fi 6E and Intel 2.5 Gigabit Ethernet. Plus, a TUF LANGuard design ensures optimized surge tolerance for greater protection.

Two-Way AI Noise Cancelation

Reduce background noise for crystal-clear communication in games or video conferences.

Cool by Design

Use AI Cooling II to balance thermals and acoustics of any build with a single click. Enlarged VRM, PCH, and M.2 heat sinks, hybrid fan headers, and Fan Xpert 4 utility via Armoury Crate allow for comprehensive cooling.

Aura Sync RGB Effects

An edge lighting design, addressable RGB headers, and RGB strip header support let you set the mood for your favorite games.

DIY Design

A PCIe slot Q-release, M.2 Q-latch, Q-LED, and SafeSlot allow for easy installation of components, meaning you can get up and running fast.

USB 3.2 Gen 2

Doubling the speed of its predecessor, USB 3.2 Gen 2 features a maximum throughput of 10 Gb/s when used with compatible devices and is synonymous with USB 3.1 Gen 2.

Items Included

• ASUS TUF GAMING Z790-PLUS WIFI LGA 1700 ATX Gaming Motherboard

• 2 x SATA Cables

• 2 x M.2 Rubber Packages

• ASUS Wi-Fi Moving Antenna

• TUF Gaming Sticker

• Screw Package for M.2 SSD

• Limited 3-Year Manufacturer Warranty
